SECTION I. CONTROLS AND INDICATORS
Your Cub Cadet Tractor has been safety engineered.
This section gives a brief description of the function
and location of the various controls and indicators.
Thoroughly acquaint yourself with all the controls and
indicators before attempting to start or operate the
tractor.
A. Low Oil Indicator
B. Hour Meter
C. Power Take-Off (PTO) Control Switch
D. Ignition/Light Switch
E. Throttle Control Lever
F. Choke Control
G. Brake Pedal Lock
H. Cruise Control Lever
I. Brake Pedal
J. Forward Control Pedal
K. Reverse Control Pedal
L. Lift Handle
M. Lift Height Indicator
N. Seat Adjustment Lever
O. Transmission Release Lever
P. Fuses (Not Shown)
Q. Safety Interlock Switches (Not Shown)
Figure 3
AB
C
F
E
H
G
D
I
J
K
O
L
N
M
