Cub Cadet LT1042 Parts Manual

13
PEDAL ASSEMBLY
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 647-0031B Control Assembly, Brake 1
2 647-0049A Control Assembly, Hydro 1
3 710-0726 Screw, Self-tapping, 5/16-12, 0.75 4
4 710-0650 Screw, Self-tapping, 5/16-18, 0.875 1
5 710-1260A Screw, 5/16-18, 0.750 2
6 783-0773A Pedal, Brake 1
7 711-04159B Pin, 3/8-16, 3/8 x 2.68 1
8 712-04065 Nut, Nylon Lock, 3/8-16 2
9 712-3004A Nut, Flange Lock, 5/16-18, Gr5 2
10 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 5
11 714-0111 Pin, Cotter, 3/32, 1.0 2
12 719-0584A Pedal, Hydro Control 1
13 732-0335 Spring, Compression, .405 x 1.17 1
14 732-0955 Spring, Extension, .50 OD x 1.41 Lg 1
15 732-0963 Spring, Extension, .50 Dia x 6.37 Lg 1
16 735-3049 Pad, Brake, Control 1
17 683-04185 Bracket, Lockout, Hydro 1
18 710-1611B Screw, Torx Hd. Tapp. 5/16-18 x .75 1
19 736-0187 Washer, Flat .64 ID x 1.24 x .06 2
20 736-3008 Washer, Flat, .344 x .750 x .120 1
21 738-0155 Shoulder, Screw .437 1
22 738-0380 Shoulder, Screw 3/8-16 1
23 741-0225 Bearing, Hex Flange 2
24 741-3065B Bearing, Hex Flange, .628 ID, Split 2
25 747-04096 Rod, Control, Cruise 1
26 747-04093 Rod, Control, Brake Lock 1
27 748-04039B Latch, Cruise 1
28 783-04612 Bracket, Support, Stearing 1

Cub Cadet LT1042 Specifications

General

Style	Tractor
Color	Yellow
Cutting Width	-
Cutting Height	-
Cutting Method	Optional Side Discharge
Number of Blades	-
Drive System	Rear Wheel Drive
Case Size: U1R	12V
Noise Level	-
Features	Cruise Control
Accessories	-
Motor / Engine Model	Kohler Courage SV590
Power Output	-
Cylinders	1
Generator	-
Power / Fuel Type	Gasoline
Fuel Tank Volume	13.2 liters (3.5 US gal.; 2.9 Imp. gal)
SAE 5W30 (below 32°F/0°C)	SG or SL
w/o Filter: 44 oz. (1	1.5 L (1.59 US. qt

Weight and Dimensions

Depth	1730 mm
Height	1090 mm
Width	1143 mm
Net Weight	226 kg
