Page #21 background imageLoading...
Page #21 background image
21
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 618-04124A Spindle Assembly 2
2 683-04171 Deck Weldment, 42 inch 1
3 683-0254B Bracket, Deck Hanger LH 1
4 710-0751 Screw, Hex Cap, 1/4-20, .620, Gr5 2
5 710-0650 Screw, Self-tapping, 5/16-18 x .875 8
6 710-0817 Screw, Self-tapping, 5/16-18 x 1.25 1
7 710-0726 Screw, Self-tapping, 5/16-12 x .75 4
8 710-0599 Screw, Self-tapping, 1/4-20 x .50 5
9 710-3096 Screw, 3/8-16 x 2.0 2
10 711-04069 Pin, Grasscatcher 1
11 712-3006 Nut, Hex, 1/4-20, Gr5 2
12 712-0417A Nut, Flange, 5/8-18 2
13 712-04064 Nut, Hx. Nylon Lock, 1/4-20 1
14 712-04065 Nut, Hx. Nylon Lock, 3/8-16 6
15 712-0641 Nut, Hex, M16-1.5 1
16 731-1032B Chute Assembly, Side Discharge 1
17 710-0134 Carriage Screw, 1/4-20, .62 1
18 714-0470 Pin, Cotter, 1/8 x 1.25 2
19 717-04074 Adjustment Gear, Deck 1
20 721-04041 Coupler, Hose 1
21 726-0233 Nut, Push, .25 ID x .50 OD 2
22 732-0306A Spring, Extension, .531 x 1.75 1
23 732-04247 Spring, Extension .850 x 6.415 1
24 734-0973 Wheel Deck 5.0 x 1.38 2
25 734-04039 Wheel Deck 5.0 x 1.38 2
26 736-0119 Washer, Lock, 5/16, Regular Duty 1
27 736-0270 Washer, Belleville, .265 x .75 x .062 2
28 736-0267 Washer, Flat, .385 x .87 x .06 2
29 736-0760 Washer, Lock 1
30 736-3039 Washer, Flat, .406 x 1.5 x .105 1
31 737-04003B Port, Water 1
34 742-04101 Blade, 21.20 Lg, 3-in-1 2
35 747-1116 Rod, Handle, Deck Release .375 Dia 2
36 712-3087 Wing Nut, 1/4-20 1
37 731-2363 Baffle, Mulch 1
38 754-04060 Belt, V-Type 1
39 756-04129 Pulley, Idler, 4.25 Dia. 2
40 783-1146A Skirt, Deck 1
41 783-04327 Cover, Belt 2
42 783-04491 Idler Bracket, Pivot 1
43 710-04226 Bolt, Spindle, 3/4-16, 5.85 2
44 712-3078 Nut, Flange Lock, 3/4-16 2
45 736-0315 Washer, Flat, .760 x 1.5 x .120 2
46 737-3000 Lube Fitting, 3/16 2
47 748-3065 Spacer, Spindle 4
48 750-1000 Spacer, 1.322 2
49 756-04086 Pulley, 6.3 Dia. 2
50 719-04110 Housing, Spindle 2
51 721-3018A Seal, Oil 4
52 741-04129 Cone Bearing, Tapered Roller, .750 4
53 741-04130 Cone Cup, Tapered Roller, .750 4
54 750-3190A Spacer, Bearing, .780 x 10 x 1.0425 2
42-INCH MOWER DECK
