Cub Cadet LT1042 Parts Manual

25
50-INCH MOWER DECK
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 16606 Hook, Retainer 1
2 618-04129A Spindle Assembly 3
3 683-0254B Hanger Bracket Assembly 1
4 683-04098 Idler Bracket 1
5 683-04075 Weldment, 50-inch Deck 1
6 703-3279 Chute Stop 1
7 710-0347 Screw, 3/8-16, 1.75 2
8 710-3103 Screw, 5/16-18 x 2.00 1
9 710-0528 Screw, 5/16-18, 1.25, Gr5 8
10 710-0599 Screw, 1/4-20 x 0.5 6
11 710-0726 Screw, 5/16-18 x.625 1
12 710-1260A Screw, 5/16-18 x .75 12
13 710-3168 Screw, Carriage, 3/8-16 x 1.0 1
14 710-3178 Screw, Carriage, 3/8-16 x .75 1
15 736-0300 Washer, Flat, .406 x .875 x .059 2
16 712-04065 Nut, Nylon Lock, 3/8-16 1
17 712-0417A Nut, Hex, Flange, 5/8-18 2
18 712-04063 Nut, Nylon Lock, 5/16-18 1
19 712-0431 Nut, Flange Lock, 3/8-16 5
20 712-3010 Nut, Hex, 5/16-18, Gr5 4
21 712-3019 Nut, 7/16-14 2
22 631-04070 Chute Assembly, Side Discharge 1
23 714-0470 Pin, Cotter, 1/8 x 1.25 1
24 714-3004 Pin, Cotter, 3/32 x 1.25 2
25 717-04074 Deck Adjustment Gear 1
26 711-1737 Roller Pin 1
27 732-0306A Spring, Compression, .531 x 1.75 1
28 732-0459B Spring, Extension, .94 x 6.74 2
29 734-04039 Deck Wheel, 5.0 2
30 734-0973 Deck Wheel, 5.0 2
31 736-0119 Washer, Lock, 5/16 1
32 736-0407 Washer, Bell, .45 x 1.0 x .062 1
33 736-0406 Washer, Flat, .442 x 1.38 x .060 1
34 737-3000 Fitting, Lube, 3/16 1
35 738-0373 Shoulder Screw 1
36 738-3005 Screw, Shoulder, .68 x 1.59 1
37 742-04068A Blade 3
38 747-1116 Rod, Deck Release .375 Dia 2
39 750-0151 Spacer, .550 x .755 x 1.1 2
40 754-04048 Belt, V-Type, Aramid 1
41 756-04129 Pulley, Idler, 3.5” 2
42 750-0151 Spacer, 1.1” 2
43 783-04399 LH Belt Cover 1
44 783-04400 RH Belt Cover 1
45 783-04414 Deck Skirt, Center 1
46 783-04415 Deck Skirt, RH 1
47 731-3005 Roller 1
48 731-04651 Baffle, Mulch 1
49 712-0641 Nut, Hex, M16-1.5 2
50 736-0760 Washer, Lock 2
51 737-04003B Port, Water 2
52 721-04041 Coupler, Hose 1
53 710-04226 Bolt, Spindle, 3/4-16, 5.85 3
54 712-3078 Nut, Flange Lock, 3/4-16 3
55 737-3000 Lube Fitting, 3/16 3
56 748-0433 Spacer, .730 3
57 748-3065 Spacer, Spindle 6
58 748-3101 Spacer, Blade 6
59 756-3096 Pulley 3
60 719-04110 Housing, Spindle 3
61 721-3018A Seal, Oil 6
62 741-04129 Cone Bearing, Tapered Roller, 6
63 741-04130 Cone Cup, Tapered Roller, .750 6
64 750-3190A Spacer, Bearing, .780 x 10 x 2
REF.
NO.
PART
NUMBER DESCRIPTION QTY.

Cub Cadet LT1042 Specifications

General

Style	Tractor
Color	Yellow
Cutting Width	-
Cutting Height	-
Cutting Method	Optional Side Discharge
Number of Blades	-
Drive System	Rear Wheel Drive
Case Size: U1R	12V
Noise Level	-
Features	Cruise Control
Accessories	-
Motor / Engine Model	Kohler Courage SV590
Power Output	-
Cylinders	1
Generator	-
Power / Fuel Type	Gasoline
Fuel Tank Volume	13.2 liters (3.5 US gal.; 2.9 Imp. gal)
SAE 5W30 (below 32°F/0°C)	SG or SL
w/o Filter: 44 oz. (1	1.5 L (1.59 US. qt

Weight and Dimensions

Depth	1730 mm
Height	1090 mm
Width	1143 mm
Net Weight	226 kg
