Cub Cadet LT1042 Parts Manual

5
DRIVE SYSTEM
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 17840 Bracket, Mounting, Transaxle 2
2 618-04145 Hub Assembly, Wheel 2
3 618-0319 Transmission, Hydrostatic 1
618-04228 Transmission, Hydrostatic w/ Drain 1
4 629-04124 Harness Assembly, Ground & Reverse 1
5 783-04442 Bracket Assembly, Idler, Center Dbl 1
6 710-1266 Hex Cap Screw, 5/16-18,3.5, Gr5 4
7 710-0227 Screw, #8-18, 0.500 2
8 710-0344 Hex Cap Screw, 3/8-16, 1.50, Gr5 3
9 710-0726 Screw, 5/16-12, 0.75 6
10 710-0599 Screw, 1/4-20, 0.5 1
11 710-3007 Screw, #12-24, 0.375 3
12 710-3011 Hex Cap Screw, 3/8-16, 2.25, Gr5 1
13 710-0809 Hex Cap Screw, 5/16-18, 1.25, Gr5 1
14 710-0627 Hex Cap Screw, 5/16-24 x .750 2
15 711-0832 Ferrule, 3/8-24 x .375 Dia 1
16 712-0291 Nut, Hex Lock, 1/4-20 1
17 712-0333 Nut, Hex, 1/2-20, Gr2 1
18 712-04065 Nut, Nylon Lock, 3/8-16 4
19 731-05130 Sleeve, 2.4” 2
20 712-04052 Nut, Nylon Lock, 5/16-18, Gr5 5
21 750-0566 Spacer, 1” 1
22 712-3017 Nut, Hex, 3/8-16, Gr8 3
23 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 2
24 714-0111 Pin, Cotter, 3/32, 1.0 1
25 725-0157 Cable, Tie, 3/16 x .05 x 7.4 2
26 725-1644 Switch, Spring, Short 1
27 726-0154 Tie, Cable, Push Mount 7.5 Lg 1
28 726-0320 Plate, Insulator Nut 1
29 731-1449A Fan, Blade, 10” 1
30 732-0209 Spring, .48 OD x 2.03 Extension 1
31 732-0429A Spring, Extension, .50 Dia x 3.97 Lg 1
32 732-0716 Spring, Extension, .59 OD x 4.00 Lg 1
33 732-0729 Ring, Wire 1
34 732-0994 Spring, Extension, .500 Dia x 7.0 1
35 732-3118 Spring, Extension, 3/8 OD x 1.44 1
36 710-0502A Screw, 3/8-16, 1.25 1
37 736-0169 Washer, Lock, 3/8 , Regular Duty 1
38 736-0866 Washer, Flat, .755 x 1.92 x .060 2
39 736-0242 Belle Washer 2
40 736-3010 Washer, Flat, .407 x .812 x .135 1
41 738-0372B Spacer, Shoulder, 1.00 x .38 x .38 1
42 747-1149 Rod, Hydro Bypass 1
43 747-04139 Rod, Brake, Hydro 1
44 747-1151 Rod, Control, Hydro 1
45 756-0978A Pulley, Engine, 3.56 Dia. 1
46 754-0461 Belt, V Type, Poly 1
47 756-0116A Pulley, Idler, V Type x 3.06 Dia 2
48 756-0981B Pulley, Idler, Flat 2.75 OD 1
49 756-04111 Pulley, Engine, 4.11Dia. 1
50 783-0810B Bracket, Transmission, Torque Hydro 1
51 783-1019 Bracket, Actuator, Switch 1
52 736-0320 Washer, Flat, .38 x 1.92 x .060 1

Cub Cadet LT1042 Specifications

General

Style	Tractor
Color	Yellow
Cutting Width	-
Cutting Height	-
Cutting Method	Optional Side Discharge
Number of Blades	-
Drive System	Rear Wheel Drive
Case Size: U1R	12V
Noise Level	-
Features	Cruise Control
Accessories	-
Motor / Engine Model	Kohler Courage SV590
Power Output	-
Cylinders	1
Generator	-
Power / Fuel Type	Gasoline
Fuel Tank Volume	13.2 liters (3.5 US gal.; 2.9 Imp. gal)
SAE 5W30 (below 32°F/0°C)	SG or SL
w/o Filter: 44 oz. (1	1.5 L (1.59 US. qt

Weight and Dimensions

Depth	1730 mm
Height	1090 mm
Width	1143 mm
Net Weight	226 kg
