Adjusting the Seat
Seat styles vary by rider model.
Knob Adjustment Seat
To adjust the position of the seat, lift the seat forward and loosen
the seat adjustment knob. Slide the seat forward or rearward to
the desired position; then tighten the adjustment knob. Make
sure seat is locked into position before operating the tractor. See
Figure 3-5.
Lever Adjustment Seat
To adjust the position of the seat, pull up and hold the seat
adjustment lever. Slide the seat forward or rearward to the
desired position; then release the adjustment lever. Make sure
seat is locked into position before operating the tractor. See
Figure 3-6.
WARNING! Before operating the tractor, make sure
the seat is engaged in the seat-stop. Engage the
parking brake. Stand behind the machine and pull
back on seat until it clicks into place.
Gas and Oil
The fuel tank is located under the hood and has a capacity of
three and-a-half gallons. Remove the fuel cap by turning it
counterclockwise. Use only clean, fresh (no more than 30 days
old), unleaded gasoline. Do not overfill the tank.
The tractor is equipped with a tethered, ratcheting cap, STOP
filling tank once fuel is seen inside the filler neck. This ensures
that a proper expansion volume is created. Do NOT top off tank.
See Figure 3-7.
WARNING! Use extreme care when handling
gasoline. Gasoline is extremely flammable and the
vapors are explosive. Never fuel the machine
indoors or while the engine is hot or running.
Extinguish cigarettes, cigars, pipes and other
sources of ignition.
NOTE: Your tractor is shipped with oil in the engine. However,
you MUST check the oil level before operating.
CAUTION: Always check the engine oil level before
each use as instructed in the separate Engine
Owner’s Manual. Add oil as necessary. Failure to do
so may result in serious damage to your engine.
Figure 3-5
Figure 3-6
Figure 3-7
11
Section 3 — ASSembly & Set-Up
