Cub Cadet RT 45 Parts Manual

1313
Model Series 400
Ref. Part Number Description
1. 634-04736 Complete Whl. Ass., 13 x 5 x 6
634-04735 Rim, 6.0 X 3.25
734-04163A Tire, 13 x 5 x 6
2. 714-0143A Klik Pin
3. 684-04168 Idler Pulley Assembly
4. 710-0331 Hex Head Screw, ⁄-24 x 2.25
5. 710-0170 Hex Head Screw, ⁄-24 x .625
6. 710-0599 Self Tapping Screw, ⁄-20 x .500
7. 710-0606 Hex Head Screw, ⁄-20 x 1.50
8. 710-0672 Hex Head Screw, ⁄-18 x 1.25
9. 710-1880 Hex Head Screw, ⁄-18 x .75, Patch
10. 736-0315 Washer, Flat, .760 x 1.50 x .120
11. 712-04064 Nylon Hex Lock Nut, ⁄-20
12. 712- 0700 Nut, 9/16-18, Flange Lock
13. 718-04407 Hub, ⁄ Spline
14. 732-04085 Extension Spring, .480 OD X 5.00 LG
15. 732-04276A Extension Spring, LT5 PTO
16. 936 - 0119 Lock Washer, ⁄
17. 736-0173 Washer, .28 x .74 x .063
18. 714-04043 Cotter Pin, Bow Tie
19. 736-0343 Flat Washer, .330 X 1.25 X .120
Ref. Part Number Description
20. 936-0452 Bell Washer, .396 x 1.140 x .095
21. 736-3092 Flat Washer, .265 x 1.0 x .030
22. 738-04425 Shoulder Screw, .342 x .335 ⁄-28
23. 748-04087A Pivot Idler Spacer
24. 750-04571 Shoulder Spacer, .260 x .785 x .538
25. 750-04907 Pivot Idler Spacer
26. 1916657 V-Belt, 4L x 25.375 Long
27. 1916658 V-Belt, 3L x 29.125 Long
28. 756-04198A Engine Pulley
29. 756-04355 Transmission Pulley
30. 756-0625 Cable Roller
31. 786 -04312 Idler Bracket, Forward
32. 786-04343 Cover Plate
33. 786-04346 Idler Bracket, Reverse
34. 786-04416A Mounting Frame, RH
35. 786-04415B Mounting Frame, LH
36. 786-04357 Pulley Bracket
37. 786-04371 Pulley Shield
38. 642-04071 Tine Assembly, LH
39. 642-04072 Tine Assembly, RH
40. 911- 0 415 Clevis Pin, .375 x 1.75
