Cub Cadet RT 45 Parts Manual

1919
Model Series 450
Ref.
Part Number Description
1. 6 8 6 - 0111 Belt Cover Bracket Assembly
2. 710-0170 Hex Bolt, ⁄-24 x .625
3. 710-0513 Hex Bolt, ⁄-28 x .75”
4. 710-0520 Hex Washer Screw, ⁄-16 x 1.50”
5. 710-1039 Hex Bolt, ⁄-24 x 1.0
6. 710-1652 Hex Washer Screw
7. 710-3005 Hex Cap Screw, ⁄-16 x 1.25
8. 712-0266A Lock Jam Nut, ⁄-16
9. 712- 04063 Flangelock Nut, 5/16-18
10. 914-0104 Internal Cotter Pin
11. 912-3066 Hex Nut, 1/2-20
12. 936-0921 Washer, Lock, 1/2
13. 936-0176 Flat Washer, .25 ID x .93 OD
14. 936-0271 Spring Washer, .317 ID x .625 OD
15. 750-0194 Hub, .636 ID x 1.00 OD x .94
16. 936-0452 Bell Washer, .396 ID x 1.14 OD
17. 738-0876A Shoulder Nut, ⁄-20
18. 9 46 -1117 Clutch Cable
19. 747-1159 Idler Pulley Rod
20. 954-0434 V-Belt
21. 756-0405 Flat Idler w/ Flange, 3.75 OD
Ref.
Part Number Description
22. 756-0971 Outer Engine Pulley Half
23. 756-0972 Inner Engine Pulley Half
24. 756 -1162 Input Pulley
25. 786-0064A Idler Bracket
26. 786-0185A Belt Keeper Bracket
27. 786-0187 Shift Cover Bracket
28. 786-0193 Idler Belt Keeper
29. 934-04365A Wheel Assembly, 16.0 x 4.6 x 8
30. 936-3020 Flat Washer, .271 ID x .630 OD
31. 784-0158A Belt Cover
32. 710-0606 Hex Head Screw, ⁄-20
33. 712- 04064 Flange Lock Nut, ⁄-20
34. 710-0382 Hex Bolt, ⁄-13 x 5.0
35. 712- 04150 Flange Lock Nut, ⁄-13
36. 723-0381† Counterweight, 40 lbs.
37. 936-0326 Flat Washer
38. 936 -0179 Washer, Flat, 1/2 x 1.25 x .100
39. 710-0653 Hex Screw, ⁄-20 x .375
40. 731-1595† Counterweight
41. 712-0392 Lock Nut
42. 710-0506 Hex Head Screw, 1/2-13 x 5.50
† If Equipped
