Cub Cadet RT 45 Parts Manual

2121
Model Series 450
Ref.
Part Number Description
1. 611- 0 021 Shaft Assembly, Tine, 18T
2. 611- 0128 Shaft Assembly, Jack
3. 611- 0129 Shaft Assembly, Shift Input
4. 611- 0 4074A Shaft Assembly, Wheel, 33T
5. 617-0058 Gear Assembly, 30T Reverse Idler
6. 617- 0 059 Gear Assembly, 30T Tine Idler
7. 617-0060 Sprocket Assembly, 9T Tine Input
8. 617-0061 Sprocket Assembly, 10T Whl Input
9. 617- 0062 Gear Assembly, 11T
10. 686-0108A RH Chain Case Housing Assembly
11. 710-0376 Hex Head Screw, 5/16-18 x 1.00
12. 710-1652 Screw, 1/4-20 x 0.625
13. 710-04484 Screw, :5/16-18 x 0.75
14. 750-0664 Spacer, .505 ID x .88 OD x .440
15. 711-1349A Input Shaft, .75
16. 712- 0378 Nut, Hex, 7/16-20
17. 712-04063 Nut, Flangelock, 5/16-18
18. 913-0367 Endless Chain, #420 x 50 Links
19. 913- 0484 Endless Chain, #50 x 54 Links
20. 716-0865 Snap Ring, .500
21. 717- 0853A Clutch Collar
22. 717-1582A Gear Spur, 44T
23. 717-1583 Gear Spur, 30T
24. 717-1584 Gear Spur, 30T
25. 717-1585 Gear Spur, 44T
26. 717-1587 Gear Spur, 44T
Ref.
Part Number Description
27. 717-1594 Gear Spur, 16T
28. 921-0378 Shaft Seal, 1.0
29. 721-0379 Shaft Seal, .75
30. 786-0238 Positioner Gear Bracket
31. 726-0277 Tapered Cap Plug
32. 732-04778 Compression Spring, .230 OD
33. 936-0163 Washer, Flat, 1.03 x 1.62 x .03
34. 936- 0171 Washer, Lock, 7/16
35. 936-0226 Washer, Flat,.474 x .879 x .064
36. 936-0351 Washer, Flat, .760 ID x 1.50 OD
37. 736-0407 Washer, Bell,.45 x 1.00 x .062
38. 736-0518 Washer, Thrust, .445 x 1.92 x .060
39. 736-3088 Washer, Flat,1.595 x .635 x .062
40. 686-04129 LH Chain Case Housing
41. 950-0671 Spacer, .75 x 2.0 x .50
42. 738-0645 Shaft Detent, .5 DIA
43. 738-0648 Shaft, Jack, .625 x 2.385
44. 738-04424A Shaft, Jack, .6250 x 5.0050
45. 941-0600 Ball Bearing, 17 x 40 x 12:6203
46. 941-0420 Flange Bearing, 1.0 x 2.5 x 1.38
47. 741-0421 Flange Bearing, .75 x 2.5 x 1.38
48. 941-0563 Ball Bearing, 17 x 40 x 12:6203
49. 741-0862 Ball, Detent, .250
50. 750-0258 Spacer, .315 x .750 x .375 LG
51. 950-0570 Spacer, 1.0 ID x 2.0 OD x.5 LG
— 986-04074B Gear Case Assembly Complete
