Cub Cadet RT 45 Parts Manual

43
170-T0B Cylinder Head
Ref.
Part Number Description
1 710-04968 Bolt M6×16
2 951-11054 Valve Cover
3 731-07059 Breather Hose
3a 726 - 04101 Hose Clamp
4 951-11565 Valve Cover Gasket
5 951-11892 Rocker Arm Assembly
6 751-11124 Nut, Pivot Locking
7 751-1112 3 Adjusting Nut ,Valve
8 951-11893 Rocker Arm
9 710-04902 Bolt, Pivot
10 951-11895 Push Rod Guide
11 951-12000 Retainer, In.Valve Spring
12 951-12002 Adjuster, Exh Valve
13 951-12003 Retainer, Ex.Valve Spring
14 951-12004 Valve Spring
15 951-1189 4 Intake Valve Seal
16 710-04933 Bolt M8×55
17 951-10668A Cylinder Head Assembly
(Incl Ref. 4,6-15,17,20,
25,26,38,42 & 43)
18 951-10292 Spark Plug/F6Rtc
Ref.
Part Number Description
19 710-05276 Muer Stud M8×36
19 951-10657 Muer Stud Assembly
24 710-05101 Stud M6×110
25 951-11567 Carburetor Insulator Gasket
26 951-11568 Carburetor Insulator
27 951-11569 Carburetor Gasket
38 951-11572 Gasket, Cylinder Head
39 951-10648 Push Rod
40 951-11899 Tappet
41 715- 04090 Dowel Pin 10×16
42 951-10647A Valve Kit
43 951-10647A Valve Kit
114 951-11063A Valve Cover Kit
951-10819 Cylinder Head Service Kit
(Incl Ref. 4,15,16 & 38)
951-12120 Gasket Kit, External
(Incl Ref. 4,20,25,26,27,29 & 68)
951-12121 Gasket Kit, Complete
(Incl Ref. 4,20,25,26,27,29,38,52,
53,62,66,68 & 70)
