Cub Cadet RT 45 Parts Manual

69
Briggs & Stratton Engine Model 12T102
Ref. Part No. Description
1 BS-699510 Cylinder Assembly
2 BS-796961 Kit-Bushing/Seal (Magneto Side)
3 BS-299819s Seal-Oil (Magneto Side)
5 BS-797439 Head-Cylinder
7 BS-698210 Gasket-Cylinder Head
11 BS-790632 Tube-Breather
12 BS-699485 Gasket-Crankcase
13 BS-699482 Screw (Cylinder Head)
15 BS-691686 Plug-Oil Drain
15A BS-691682 Plug-Oil Drain
16 BS-797074 Crankshaft
18 BS-699696 Cover-Crankcase
20 BS-692550 Seal-Oil (PTO Side)
21 BS-281658s Cap-Oil Fill
22 BS-699478 Screw (Crankcase Cover/Sump)
23 BS-699488 Flywheel
24 BS-796335 Key-Flywheel (Steel)
— BS-222698s Key-Flywheel (Aluminum)
25 BS-795429 Piston Assembly (Standard)
— BS-795430 Piston Assembly (.020” Oversize)
26 BS-791969 Ring Set (Standard)
— BS-793001 Ring Set (.020” Oversize)
27 BS-691866 Lock-Piston Pin
28 BS-499423 Pin-Piston
29 BS-798813 Rod-Connecting
32 BS-797437 Screw (Connecting Rod)
33 BS-499642 Valve-Exhaust
34 BS-795443 Valve-Intake
35 BS- 691304 Spring-Valve (Intake)
36 BS-691304 Spring-Valve (Exhaust)
37 BS-699661 Guard-Flywheel
40 BS-692194 Retainer-Valve
45 BS-690977 Tappet-Valve
46 BS-693404 Camshaft
48 N/A Short Block
51 BS-692555 Gasket-Intake
55 BS-791848 Housing-Rewind Starter
58 BS-693389 Rope-Starter
60 BS-490652 Grip-Starter Rope
65 BS-699228 Screw (Rewind Starter)
78 BS-793480 Screw (Flywheel Guard) (M5x14mm)
95 BS-691636 Screw (Throttle Valve)
Ref. Part No. Description
97 BS-797628 Shaft-Throttle
98 BS-797156 Kit-Idle Speed
104 BS-797622 Pin-Float Hinge
105 BS-797139 Valve-Float Needle
108 BS-692567 Valve-Choke
109 BS-790624 Shaft-Choke
117 BS-798661 Jet-Main (Standard)
118 N/A Jet-Main (High Altitude)
121 BS-797634 Kit-Carburetor Overhaul
122 BS-795208 Spacer-Carburetor
125 BS-798653 Carburetor
127 BS-797633 Plug-Welch
130 BS-797630 Valve-Throttle
133 BS-797136 Float-Carburetor
137 BS-797625 Gasket-Float Bowl
146 BS-690979 Key-Timing
155 BS-797442 Plate-Cylinder Head
161 BS-790631 Base-Air Cleaner
163 BS-696024 Gasket-Air Cleaner
187 BS-791874 Line-Fuel (Formed)
188 BS-699479 Screw (Control Bracket)
190 BS-699220 Screw (Fuel Tank)
192 BS-797440 Adjuster-Rocker Arm
209 BS- 691278 Spring-Governor (Platinum)
— BS-692571 Spring-Governor (# 6 Hole)
219 BS-693578 Gear-Governor
220 BS - 691724 Washer (Governor Gear)
222 BS-793107 Bracket-Control
227 BS-794367 Lever-Governor Control
238 BS- 691300 Cap-Valve
271 BS-694256 Lever-Control
276 BS-797632 Washer-Sealing
281 BS -793122 Panel-Control
300 BS-693593 Muer
304 BS-699598 Housing-Blower
305 BS-699481 Screw (Blower Housing)
306 BS-795334 Shield-Cylinder
307 BS-699483 Screw (Cylinder Shield)
332 BS-792723 Nut (Flywheel)
333 BS-796964 Armature-Magneto
334 BS-699477 Screw (Magneto Armature)
337 BS-491055s Plug-Spark
