75
170-TU Crankshaft & Crankcase
Ref.
Part Number Description
50 951-12111 Piston Ring Set
51 951-11632 Piston Pin Snap Ring
52 951-12007 Piston
53 951-11633 Piston Pin
54 710-04915 Bolt M6×12
55 951-11113 Air Shield
56 951-11573 Connecting Rod Assembly
57 951-11356 Governor Arm Shaft
58 736-04461 Washer 5.2×1.9
59 951-11574 Governor Seal
60 714-04074 Cotter Pin
61 951-11575 Camshaft Assy.
62 951-11369 Radial Ball Bearing, 6205
63 951-12160 Crankshaft Assembly
64 951-10307 Woodru Key
65 951-11576 Governor Gear/Shaft Assembly
66 715-04092 Dowel Pin 7×14
Ref.
Part Number Description
67 715-04089 Dowel Pin 9×14
68 951-11371 Crankcase Cover Gasket
69 951-12125 Cover Comp, Left Crankcase
70 710-04932 Bolt M8×32
71 951-11283 Oil Plug
72 951-11578 Oil Seal, 25×41.25×6
73 951-12551 Short Block
(Incl.6,22,27,28,44,46,47,
50-53,56-70,72-75)
74 951-12514 Oil Drain Plug
77 951-12126 Oil Seal 25×41.25×6
125 951-12573 Gasket Kit - External
(Incl.6,22,27-29,31)
126 951-12572 Gasket Kit - Complete
(Incl.6,22,27-29,31,44,
58,59,68,72,75)
130 952Z170-TU Complete Engine
