Cub Cadet RT 45 Parts Manual

79
170-TU Cylinder Head
Ref.
Part Number Description
1 710-04968 Bolt M6×16
2 951-11054 Valve Cover
3 726-04101 Breather Hose Clamp
4 731-07059 Exhaust Piping
6 951-11565 Valve Cover Gasket
7 951-11892 Rocker Arm Assembly
8 751-11124 Nut, Pivot Locking
9 751-1112 3 Adjusting Nut ,Valve
10 951-11893 Rocker Arm
11 710-04902 Bolt, Pivot
12 951-11895 Push Rod Guide
13 951-12000 Retainer, In.Valve Spring
14 951-12002 Adjuster, Exh Valve
15 951-12003 Retainer, Ex.Valve Spring
16 951-12004 Valve Spring
17 951-11894 Intake Valve Seal
18 710-04933 Bolt M8×55
19 951-10819 Cylinder Head Service Kit
Ref.
Part Number Description
Incl.4,15,16,38)
951-10722A Cylinder Head Assembly
(Incl.6,8-17,19,22,28,
29,44,48,49)
20 951-10292 Spark Plug/F6Rtc
44 951-11572 Gasket, Cylinder Head
45 951-10648 Push Rod Kit
46 951-11899 Tappet
47 715-04108 Dowel Pin 10×16
48 951-10647A Valve Kit
49 951-10647A Valve Kit
124 951-11063A Valve Cover Kit
125 951-12573 Gasket Kit - External
(Incl.6,22,27-29,31)
126 951-12572 Gasket Kit - Complete
(Incl.6,22,27-29,31,44,
58,59,68,72,75)
130 952Z170-TU Complete Engine
