85
170-VU Crankshaft & Crankcase
Ref.
Part Number Description
52 951-12111 Piston Ring Set
53 951-11632 Piston Pin Snap Ring
54 951-12007 Piston
55 951-11633 Piston Pin
56 710-04915 Bolt M6×12
57 951-11113 Air Shield
58 951-11573 Connecting Rod Assembly
59 951-11356 Governor Arm Shaft
60 736-04461 Washer 5.2×1.9
61 951-11574 Governor Seal
62 714-04074 Cotter Pin
63 951-11575 Camshaft Assy.
64 951-11369 Radial Ball Bearing, 6205
65 951-12160 Crankshaft Assembly
66 951-10307 Woodru Key
67 951-11576 Governor Gear/Shaft Assembly
68 715-04092 Dowel Pin 7×14
Ref.
Part Number Description
69 715- 04089 Dowel Pin 9×14
70 951-11371 Crankcase Cover Gasket
71 951-12125 Cover Comp, Left Crankcase
72 710-04932 Bolt M8×32
73 951-11283 Oil Plug
74 951-11578 Oil Seal, 25×41.25×6
75 951-12551 Short Block
(Incl.6,22,29,30,46,48,49,
52,53,55,58-72,74-77)
76 951-12514 Oil Drain Plug
77 951-12126 Oil Seal 25×41.25×6
129 951-12573 Gasket Kit - External
(Incl.6,22,29-31,33)
130 951-12572 Gasket Kit - Complete
(Incl.6,22,29-31,33,46,
60,61,70,74,77)
131 952Z170-VU Complete Engine
To Next Page
