Cub Cadet RT 45 Parts Manual

99
Model Series 340
Ref. Part Number Description
1. 986-0091 Chain Case Assembly
2. 642-0002 Inner Tine Assembly, RH
3. 642-0003 Inner Tine Assembly, LH
4. 642-0004 Outer Tine Assembly, RH
5. 642-0005 Outer Tine Assembly, LH
6. 911-0 415 Clevis Pin, .375 x 1.75
7. 714-04043 Bow Tie Cotter Pin
8. 710-0599 Screw, 1⁄4-20 x 0.500
9. 711- 0 919 Bolt, Belt Cover
10. 712-0392 Nut, 1/4-28, Lock
11. 712-3004A Nut, 5/16-18, Flange Lock
12. 936-3020 Flat Washer, .271 x .630 x .065
13. 738-0930 Shoulder Screw, .560 x .165 5/16-18
14. 786-0056 Belt Cover
15. 710-3008 Hex Head Screw, 5/16-18 x .75
16. 712- 04063 Nut, 5/16-18, Flange Lock
17. 786-0043A Tine Shield
18. 786-0053 Bracket, Tine Shield
19. 686-0088 Idler Bracket Assembly
20. 710-0189 Hex Head Screw, 5/16-18 x 3.00
21. 710-0237 Hex Head Screw, 5/16-24 x .625
22. 710-1039 Hex Head Screw, 3/8-24 x 1.00
Ref. Part Number Description
23. 710-3005 Hex Head Screw, 3/8-16 x 1.25
24. 711-1036A Hex Nut, 5/16-18
25. 712-0266A Jamlock Nut, 3/8-16
26. 712-3029 Nut, 1/2-20, Jam
27. 736- 0112 Washer, .531 x 1.62 x .045
28. 936 - 0119 Lock Washer, 5/16
29. 736-0242 Bell Washer, .340 x .872 x .060
30. 736-0312 Flat Washer, 1.26 x 1.87 x .150
31. 936-0452 Bell Washer, .396 x 1.140 x .095
32. 946-0918 Forward Clutch Cable
33. 948-0350 Pulley Adaptor
34. 950-0892 Spacer, .64 ID x 2.4
35. 954-0428 Belt, 4L x 41.9 LG
36. 756- 0313 Pulley 1.88 OD
37. 756-0585 Pulley 6.00 OD
38. 756-0971 Inner Engine Pulley
39. 756-0972 Outer Engine Pulley
40. 786-0039B Belt Keeper Bracket
41. 786-0129 Cable Guide Bracket
42. 786-0144 Idler Bracket
43. 786- 0149 Belt Keeper

Cub Cadet RT 45 Specifications

General

Brand	Cub Cadet
Model	RT 45
Category	Tiller
Language	English
