Sc Series 11 Sc2450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-119517-07900 LIFTER, ENGINE 1
2 CY-129900-07900 LIFTER, ENGINE 1
3 CY-26106-080162 BOLT M 8X 16 PLATED 4
4 CY-129901-11450 PROTECTER, NOZZLE 3
5 CY-119600-11460 GASKET, NOZZLE 6
6 CY-105010-11490 CAP, VALVE 6
7 CY-119517-11740 HEAD ASSY, CYLINDER 1
13 CY-119515-11800 GUIDE, VALVE 6
15 CY-119285-11990 PLUG 35 2
16 CY-23876-005000 PLUG PT 1/16,SCREW 1
17 CY-119515-11101 VALVE, INTAKE 3
18 CY-119515-11110 VALVE, EXHAUST 3
19 CY-119717-11131 SPRING, VALVE 6
20 CY-129508-11180 RETAINER, SPRING 6
21 CY-119717-11190 COTTER, VALVE 12
22 CY-119717-11340 SEAL, VALVE STEM 3
23 CY-119717-11350 SEAL, VALVE STEM 3
24 CY-22351-060012 SPRING PIN 6X12 2
25 CY-119515-11200 SUPPORT ASSY, ARM 1
26 CY-119515-11240 SHAFT ASSY, ROCKER 1
29 CY-119717-11260 SUPPORT, ROCKER ARM 3
30 CY-119515-11280 SPRING, SHAFT 2
31 CY-119717-11650 ARM ASSY, ROCKER 6
32 CY-129150-11230 SCREW, VALVE 6
34 CY-129150-11750 NUT M8XP1.0 6
35 CY-22242-000120 CIRCLIP 12 2
36 CY-26979-050162 SCREW M 5X16 1
37 CY-26106-080402 BOLT M 8X 40 PLATED 3
38 CY-124160-01751 COVER,FILLER 1
39 CY-119515-11380 BONNET ASSY, HEAD 1
40 CY-119717-03031 PLATE, BAFFLE 1
41 CY-119717-03070 BAFFLE, BREATHER 1
42 CY-119717-03070 BAFFLE, BREATHER 2
43 N/A DIAPHRAGM ASSY 1
44 CY-119802-03110 PLATE, DIAPHRAGM 1
45 CY-119802-03121 COVER, DIAPHRAGM 1
46 CY-119802-03131 DIAPHRAGM 1
47 CY-119802-03141 SPRING, DIAPHRAGM 1
49 CY-119515-11310 GASKET, BONNET 1
50 CY-119515-11320 COVER BONNET 1
51 CY-119515-11330 GASKET BONNET COVER 1
52 CY-22857-500100 SCREW 5X10,TAPPING 4
53 CY-22857-500100 SCREW 5X10,TAPPING 4
54 CY-22857-500160 SCREW 5X16 2
55 CY-24311-000320 O-RING 1A P-32.0 1
56 CY-26106-060202 BOLT M 6X 20 PLATED 3
57 CY-26106-060752 BOLT M 6X 75 PLATED 6
58 CY-119717-77800 PLUG, GLOW 3
59 CY-119717-77820 CONNECTOR, GLOW PLUG 1
FIG. 4. CYLINDER HEAD & VALVE COVER
Copyright 2009 Cub Cadet Yanmar LLC
