Controls & Features
4
14
Figure 4-1
Parking Brake
Deck Height
Index
Deck Lift
Pedal
Fuel Tank Cap
Cup Holder
RH Drive
Control Lever
LH Drive
Control Lever
Fuel Shut-Off Valve
ROPS (Roll Over Protective System)
FAST
SLOW
CHOK
E
OF
F
CHOK
E
ON
OF
F
RU
N
ST
AR
T
E
RWARD
START
“N”
NEUTRAL
WA RNIN
Ignition
Switch
Throttle
Control
Choke
Lever
PTO
Switch
Digital Tachometer
& Hour Meter
NOTE:
position on the tractor when facing forward while seated in the
Deck Height Index
The deck height index consists of several holes located on the
front/right of the foot platform. Each hole corresponds to a ⁄”
” at the lowest
notch to 4” at the highest notch.
Cup Holder
Deck Lift Pedal
The deck lift pedal is located on the right front corner of the foot
platform, and is used to raise and lower the mower deck.
To raise the mowing deck to the transport position, push the
upper part of the pedal all the way forward and place the clevis
pin in furthest hole from you and secure with the cotter pin.
To lower the deck, remove the clevis pin and reinsert it in the
desired cutting height and secure with cotter pin.
RH and LH Drive Control Levers
space to permit the operator to either sit in the tractor seat, or to
dismount the tractor. The levers must be fully opened out and in
the neutral position to start the tractor engine.
Consequently, these levers control all of the movements of the
tractor. Driving and steering utilizing these control levers is
quite different from conventional tractors, and will take some
the control levers.
To Next Page
