39se c t i O n 7 — se r v i c e
Changing the Spindle Assembly
block it in that position.
Make sure the blade clutch is disengaged.2.
Remove the deck cover.
4.
5.
Using a wrench or socket ratchet remove flange lock 6.
nuts, and the four hex flange bolts. Remove the spindle
Reverse the process to install the spindle assembly.7.
Tractor Creeping
Creeping is the slight forward or backward movement of the
mower when the throttle is on and the speed control pedals are
in the neutral position. If your mower creeps, see an authorized
service dealer.
Spindle Assembly
Blade
Flange Lock Nut
Spacer
Hex Flange Bolt
Support Plate
Flange Lock Nut
Hex Screw
Figure 7-5
Tractor High Speed Tracking
If the tractor tracks to one side with both drive control levers fully
forward, adjust the control levers as follows:
Check for proper and balanced air pressure in both front
and rear tires. Refill tires if necessary.
2.
to verify that the tractor is not creeping.
Recheck the tracking after making any adjustments to the 4.
transmission control rods.
If uneven tracking persists, adjust as follows:5.
If the tractor tracks to the right, adjust the left a.
If the tractor tracks to the left, adjust the right b.
control lever stop bolt to make it longer.
Recheck the tracking and fine tune the adjustment as 5.
necessary.
NOTE: If the stop bolt is adjusted too far, the tracking
problem will change sides. Make fine tuning adjustments
by shortening the same bolt.
Figure 7-6
