Lx450Lx Series

Fig 5. Suction Manifold

Ref.

Part Number Description Qty

1 CY-129005-03080 PIPE, BREATHER 1

2 CY-129410-03990 CLAMP 22 2

3 CY-129602-12101 MANIFOLD, AIR INTAKE 1

4 CY-129407-12110 GASKET, MANIFOLD 1

5 CY-26106-080202 BOLT M 8X 20 PLATED 6

6 CY-26106-080802 BOLT M 8X 80 PLATED 1

7 CY-129486-12581 JOINT, MANIFOLD 1

8 CY-129150-77511 GASKET, AIR HEATER 1

9 CY-26106-080202 BOLT M 8X 20 PLATED 4
