Cub Cadet Yanmar Lx450 - Page 15

Lx450Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
15
Fig 6. Exhaust Manifold & Muer
Ref.
Part Number Description Qty
1 CY-129411-13100 MANIFOLD, EXHAUST 1
2 CY-129550 -13110 GASKET, EXH.MANIFOLD 1
3 CY-129263-13220 STUD, M8X95 2
4 CY-123900 -13630 BOLT, M8X80 6
5 CY-119131-18320 STUD, M8X22 4
6 CY-26306-080002 NUT, M8 2
7 CY-129930 -13201 GASKET, SILENCER 1
8 CY-129659-13521 SILENCER 1
9 CY-129659-13660 STAY, SILENCER 1
10 CY-26014-080222 BOLT M 8X 22 2
11 CY-26014-080252 BOLT M 8X 25 2
12 CY-26306-080002 NUT, M8 4
