Cub Cadet Yanmar Lx450 - PTO Guard Assembly

Lx450Lx Series
Ref.
Part Number Description Qty
1 CY-198072-18320 SPRING 12 6
2 CY-1A8275-26930 SHIELD M ASSY, PTO 1
3 CY-1A8275-26950 COLLAR 2
4 CY-1A8275-26960 PLATE ASSY 1
5 CY-22137-120000 WASHER 12,POLISHED 2
6 CY-26106-080162 BOLT M 8X 16 PLATED 4
7 CY-26106-080252 BOLT M 8X 25 PLATED 2
8 CY-26756-080002 LOCK NUT M 8 PLATED 2
Copyright 2011 Cub Cadet Yanmar LLC
213
Fig 129. PTO Guard
Fig.129. PTO GUARD
0CNP5-G37900
0CNP5-G37900
129. PTO GUARD
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
SPRING 12198072-1832011 666
SHIELD M ASSY, PTO1A8275-2693012 111
COLLAR1A8275-2695013 222
PLATE ASSY1A8275-2696014 111
WASHER 12,POLISHED22137-12000015 222
BOLT M 8X 16 PLATED26106-08016216 444
BOLT M 8X 25 PLATED26106-08025217 222
LOCK NUT M 8 PLATED26756-08000218 222
(C)Copy Rights YANMAR CO.,LTD.
