Fig 11. Cooling Water System
Ref.
Part Number Description Qty
1 CY-129263-42000 PUMP ASSY, WATER 1
2 CY-129150-42059 PACKING 1
4 CY-129263- 42120 PLATE 1
8 CY-129150- 42300 FLAGNE, C. W. PUMP 1
10 CY-129054 -42320 O-RING 1
12 CY-129916 -49740 PLUG, R03 2
13 CY-24358-240310 O-RING, 5 24031 1
14 CY-26106-060202 BOLT M 6X 20 PLATED 2
15 CY-26116-060162 BOLT 6X16 3
16 CY-26577-060152 SCREW, M6X15 3
17 CY-129486-42050 GASKET, PUMP 1
18 CY-23414-080000 GASKET 8, ROUND 1
19 CY-26106-080122 BOLT M 8X 12 PLATED 1
20 CY-26106-080552 BOLT M 8X 55 PLATED 3
21 CY-26106-080602 BOLT M 8X 60 PLATED 1
22 CY-129120-42350 V-PULLEY, WATER PUMP 1
23 CY-25152-004100 V-BELT 1
24 CY-129436 -44740 FAN, COOLING 1
25 CY-129266 -44760 SPACER 1
26 CY-26014-060162 BOLT M 6X 16 4
27 CY-26014-060302 BOLT W/WASHER 6X 30 4
28 CY-129155- 49801 THERMOSTAT 1
29 C Y-12 915 0 - 49 811 GASKET, THERMOSTAT 1
30 CY-129795-49551 GASKET, COVER 1
31 CY-129350 -49560 COVER, THERMOSTAT 1
32 CY-26106-080202 BOLT M 8X 20 PLATED 2
33 CY-119620-49290 COCK ASSY 1
37 CY-121450-42450 PLUG M16 1
38 CY-124465-44950 GASKET, 16 1
39 CY-124250-49351 THERMOMETER 1
40 CY-129150- 49360 GASKET 10 1
41 CY-129263-49610 PIPE, WATER A 1
43 CY-124722-59050 CLIP, HOSE 2
44 CY-129263-49620 PIPE, WATER B 1
46 CY-124722-59050 CLIP, HOSE 2
