Fig 13. Fuel Injection Pump Lx450
Ref.
Part Number Description Qty
1 CY-729652-51570 INJECTION PUMP ASSY 1
4 CY-158553-51551 JOINT, COOLING WATER 1
5 CY-158601-51650 JOINT, OVER FLOW 1
6 CY-158552-51670 JOINT, OVER FLOW 1
14 CY-129008-51900 COVER 1
15 CY-129008-51920 BOLT M6X10 2
16 CY-119802-51090 KEY, WOODRUFF 4X16 1
19 CY-158552-51151 FLANGE 1
41 CY-158600-51270 STOPPER, TAPPET 1
42 CY-158563-51281 O-RING 1
43 CY-158563-51281 O-RING 1
44 CY-129008-51390 SETTING, DELIVERY 4
53 CY-158563-51330 SPRING, DELIVERY 4
61 CY-158601-51550 PLUG 1
62 CY-119802-51560 PLUG, BARREL 1
63 CY-158552-51571 PK(BARREL PLUG 3
64 CY-158552-51571 PK(BARREL PLUG 1
65 CY-158557-51570 PLUG 1
66 CY-158601-51570 PLUG, WATER PUMP 1
67 CY-158552-51580 LIFTER 1
68 CY-119802-51590 TIMER SET 1
69 CY-119802-51590 TIMER CMP 1
72 CY-158553-51670 O-RING, 1011 1
73 CY-119802-51680 BACKUP RING 1
74 CY-119802-51690 O RING 1
75 CY-24356 -190200 PACKING, 19020 1
76 CY-24372-000150 RING, BACKUP T2 P 15 1
77 CY-158552-51600 PACKING, HEAD 1
78 CY-158553-51630 SPRING, TIMER 1
80 CY-158553-51650 ELEMENT, THERMO 1
Ref.
Part Number Description Qty
81 CY-158553-51660 O-RING,P14 1
82 CY-158553-51680 PACKING,TIMER 1
102 CY-158601-51770 PISTON 1
103 CY-158552-51781 SPRING, ACTUATOR 1
104 CY-158601-51790 PLUG 1
106 CY-158553-51930 PLUG,M12 1
107 CY-22190-120002 SEAL WASHER 12 1
108 CY-22190-180002 WASHER, 18 1
109 CY-158553-51770 BOLT 4
112 CY-158552-52311 O-RING 1
113 CY-158552-52400 O-RING 4E S42 1
114 CY-22190-120002 SEAL WASHER 12 2
115 CY-22190-180002 WASHER, 18 2
116 CY-22217-140000 SPRING WASHER 14 1
117 CY-22312-050140 PARALLEL PIN 5X14 2
118 CY-22351-050010 SPRING PIN 5X10 2
120 CY-24311-000070 O-RING 1A P-7.0 1
121 CY-24356-190180 O-RING 4D 19018 1
122 CY-24356-190200 PACKING, 19020 1
123 CY-26106-060102 BOLT 6X 10 PLATED 1
125 CY-26450-080452 BOLT M 8X 45 4
126 CY-26776-140002 LOCK NUT M14 PLATED 1
128 CY-158552-52100 PUMP ASSY, FUEL FEED 1
129 CY-158552-52500 O-RING, PUMP 1
130 CY-129916-59020 JOINT, PIPE 12 1
131 CY-22190-120002 SEAL WASHER 12 2
132 CY-23857-060000 JOINT BOLT 6,PIPE 1
134 CY-129601-51250 RETAINER, PUMP 1
135 CY-26106-080162 BOLT M 8X 16 PLATED 1
136 CY-26106-080202 BOLT M 8X 20 PLATED 1
