Fig 16. Fuel Injection Valve Lx450
Ref.
Part Number Description Qty
1 CY-729604-53400 FUEL INJECTOR(REB 4
2 CY-114250-53080 NUT, CASE 4
3 CY-119802-53100 HOLDER ASSY, NOZZLE 4
8 C Y-1142 5 0 -5 312 0 SPRING, NOZZLE 4
9 C Y-1142 5 0 -5 313 0 SEAT, SPRING 4
10 CY-114250-53140 PLATE, STOP 4
11 CY-114250-53210 PIN 8
12 CY-129604-53300 NOZZLE ASSY 4
15 CY-119803-53400 SHIM SET 4
42 CY-129150 -59120 RETAINER, PIPE 1
45 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2
46 CY-129550-59120 RETAINER, PIPE 1
49 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2
51 CY-129601-59810 PIPE ASSY, INJECTION 1
55 CY-129601-59820 PIPE ASSY, INJECTION 1
59 CY-129601-59830 PIPE ASSY, INJECTION 1
63 CY-129601-59840 PIPE ASSY, INJECTION 1
68 CY-119802-59550 PIPE ASSY, RETURN 1
69 CY-124722-59050 CLIP, HOSE 2
70 CY-119802-59560 PIPE, FUEL RETURN 1
71 CY-129486-59551 PIPE ASSY, RETURN 3
72 CY-124722-59050 CLIP, HOSE 6
74 CY-119593-59581 CAP 1
75 CY-23080-010000 CLAMP 10 1
