Lx450Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
35
Fig 18. Generator
Ref.
Part Number Description Qty
1 CY-129795-01900 STUD 1
2 CY-119751-77200 GENERATOR, 12V-40A 1
3 CY-X0215512440 COVER 1
4 CY-X1214001430 FLAME ASSY, DRIVE 1
5 CY-119620-79200 BALL BEARING 1
6 CY-119620-79210 PLATE, RETAINER 1
7 CY-119620-79220 SCREW 4
8 CY-119620-79230 STUD 2
9 CY-X1215011050 FLAME ASSY, REAR 1
10 CY-X9490561001 NUT 1
11 CY-119620-77380 ROTOR ASSY 1
12 CY-119620-79240 BALL BEARING 1
13 CY-119620 -79250 COVER, BEARING 1
14 CY-119620-77461 PULLEY 1
15 CY-119620 -77471 NUT 1
16 CY-119620 -77490 COLLAR 1
17 CY-129423-77710 REGULATOR ASSY 1
18 CY-119620 -79260 HOLDER 1
19 CY-129052-79270 HOLDER, BRUSH 1
20 CY-119620 -77480 BRUSH ASSY 2
21 CY-119620-79280 SPRING 2
22 CY-119620 -79290 SCREW 6
23 CY-119620-79300 SCREW 1
24 CY-119620-79310 BOLT 3
25 CY-119620-79320 SCREW 2
26 CY-119620-79330 BOLT 2
27 CY-119620 -79340 BUSH, INSULATION 1
28 CY-119620-79350 NUT 2
29 CY-119620-79360 WASHER, THRUST 1
30 CY-26306-100002 NUT, M10 1
31 CY-129107-77330 ADJUSTER, BELT 1
32 CY-124732-77340 SPACER 1
33 CY-129972-77341 BOLT, ADJUSTER 1
