Lx450Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
39
Fig 1. Engine Related Lx410 & Lx450
Ref.
Part Number Description Qty
1 CY-129263-44510 TANK ASSY, SUB 1
2 CY-119225-52102 PUMP ASSY, FUEL FEED 1
3 CY-129004 -55612 BRACKET, FILTER 1
4 CY-119802-55700 SEPARATOR ASSY 1
5 CY-129100-55690 RING, RETAINING 1
6 CY-119802-55710 ELEMENT 1
7 CY-119802-55730 CUP ASSY 1
8 CY-24311-000160 O-RING 1A P-16.0 1
9 CY-24321-000650 O-RING 1A G-65.0 1
10 CY-119802-55801 FILTER, FUEL 1
