Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
13
Fig 5. Suction Manifold
Ref.
Part Number Description Qty
1 CY-129508-12110 GASKET, MANIFOLD 1
2 CY-129508-12120 MANIFOLD, AIR INTAKE 1
3 CY-26106-080202 BOLT M 8X 20 PLATED 6
4 CY-26106-080802 BOLT M 8X 80 PLATED 1
5 CY-129558-12090 HOSE,INTAKE 1
6 CY-23000-048000 CLAMP 48 1
7 CY-23000-060000 CLAMP 60 1
8 CY-129120-77502 HEATER, AIR 1
9 CY-129150-77511 GASKET, AIR HEATER 1
10 CY-26106-080352 BOLT M 8X 35 PLATED 4
