Cub Cadet Yanmar Lx490 - Page 139

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
139
Fig 74. Hydraulic Pump
Ref.
Part Number Description Qty
1 CY-1680DE-00010 HO-P(PW2-D-14A 1
2 CY-178077-15400 SEAL RING 1
3 CY-178077-15410 BACKUP RING 1
4 CY-194521-41570 PIN 11X7 2
5 CY-22252-000320 CIRCLIP 32 1
6 CY-24421-153207 SEAL TC15 32 07, OIL 1
7 CY-26016-080352 BOLT M 8X 35 4
8 CY-16800A-00020 HO-P(PW1-C-10C 1
9 CY-178070-10401 SQUARE RING 1
10 CY-194521-41570 PIN 11X7 2
11 CY-22252-000320 CIRCLIP 32 1
12 CY-24421-153207 SEAL TC15 32 07, OIL 1
13 CY-26016-080352 BOLT M 8X 35 4
14 CY-124240-01883 GASKET, PUMP 2
15 CY-22190-080002 SEAL WASHER 8S 1
16 CY-26106-080252 BOLT M 8X 25 PLATED 2
17 CY-26106-080302 BOLT M 8X 30 PLATED 1
18 CY-26106-080402 BOLT M 8X 40 PLATED 1
19 CY-26106-080802 BOLT M 8X 80 PLATED 2
20 CY-26106-081152 BOLT M 8X115 PLATED 2
