Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
143
Fig 76. Hyd. Lift Docking
Ref.
Part Number Description Qty
1 CY-198240-42130 PACKING, HOUSING 1
2 CY-1A7180-42150 GASKET,HOUSING 1
3 CY-1A8275-42910 SPACER, LIFT 1
4 CY-22312-100180 PARALLEL PIN 10X 18 2
5 CY-22312-100180 PARALLEL PIN 10X 18 2
6 CY-26106-120402 BOLT, M12X 40 PLATED 4
7 CY-26106-120702 BOLT, 12X70 6
8 CY-26216-120702 STUD M12X 70 PLATED 2
9 CY-26218-120502 STUD,BOLT 12 X 50 2
10 CY-26366-120002 U-NUT M12 4
