Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
149
Fig 79. Control Valve
Ref.
Part Number Description Qty
1 CY-1A8275-45200 VALVE ASSY, CONTROL 1
2 CY-1A8275-45230 SPRING 1
3 CY-1A8275-45240 SPRING 1
4 CY-1A8275-45280 SPRING 1
5 CY-1A8275-45310 POPPET, UNLOAD 1
6 CY-1A8275-45320 SPRING 1
7 CY-1A8275-45330 RING, WIRY SNAP 1
8 CY-1A8275-45340 SEAT, SPRING 1
9 CY-1A8275-45360 SPRING 1
10 CY-1A8275-45370 PLUG 1
11 CY-1A8275-45420 POPPET, CHECK 1
12 CY-1A8275-45440 PLATE 1
13 CY-1A8275-45500 SEAL KIT, VALVE 1
14 CY-41851-000110 PACKING, 11.0 3
15 CY-1A7880-45640 PLUG,LIFT VALVE 1
16 CY-26116-100162 BOLT M10X 16 PLATED 1
17 CY-26450-050102 BOLT, M5X10 3
18 CY-26450-080252 BOLT M 8X 25 3
