Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
165
Fig 90. Hydraulic Line
Ref.
Part Number Description Qty
1 CY-194990-22140 NUT W/WASHER 8 1
2 CY-1A8250-48000 LP PIPE, FRONT 1
3 CY-1A8250-48050 LP PIPE, REAR 1
4 CY-198220-48140 FLANGE 1
5 CY-198240-48140 FLANGE 1
6 CY-1A8275-48340 HOSE, RUBBER LP P 1
7 CY-1A8250-48500 HP PIPE, LIFT 1
8 CY-194470 -48630 CLAMP 1
9 CY-194470 -48640 CLAMP 1
10 CY-198361-48750 CONNECTOR BOLT ASSY 1
11 CY-194450-48830 CLAMP 2
12 CY-23000-035000 CLAMP 35 1
13 CY-23000-048000 CLAMP 48 2
14 CY-23414-200026 GASKET 20 2
15 CY-24311-000200 O-RING 1A P-20.0 1
16 CY-24311-000220 O-RING 1A P-22.0 1
17 CY-24311-000320 O-RING 1A P-32.0 1
18 CY-24311-000320 O-RING 1A P-32.0 1
19 CY-24311-000360 O-RING 1A P-36.0 1
20 CY-24341-000250 O-RING 1A S-25.0 1
21 CY-26106-060202 BOLT M 6X 20 PLATED 1
22 CY-26106-060352 BOLT M 6X 35 PLATED 2
23 CY-26106-060402 BOLT M 6X 40 PLATED 2
24 CY-26106-060402 BOLT M 6X 40 PLATED 4
25 CY-26106-060452 BOLT M 6X 45 PLATED 2
26 CY-26106-080162 BOLT M 8X 16 PLATED 2
27 CY-26106-080162 BOLT M 8X 16 PLATED 1
28 CY-26106-080162 BOLT M 8X 16 PLATED 2
