Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
181
Fig 103. Lamp
Ref.
Part Number Description Qty
1 CY-1A7400-53110 LAMP, REAR COMBI. L 1
2 CY-1A7890-53420 VALVE, 12V 21W 1
3 CY-26557-050162 SCREW, 5X16 2
4 CY-1A7400-53530 VALVE,12V21/5W 1
5 CY-1A7400-53560 GASKET 1
6 CY-1A7400-53570 LENS,L 1
7 CY-1A7400-53590 LENS,L 1
8 CY-1A7400-53610 LENS,L 1
9 CY-1A7400 -53120 LAMP, REAR COMBI. R 1
10 CY-1A7890-53420 VALVE, 12V 21W 1
11 CY-26557-050162 SCREW, 5X16 2
12 CY-1A7400-53530 VALVE,12V21/5W 1
13 CY-1A7400-53560 GASKET 1
14 CY-1A7400 -53580 LENS,R 1
15 CY-1A7400-53600 LENS,R 1
16 CY-1A7400-53620 LENS,R 1
17 CY-1A8275-53400 LAMP ASSY,FLASHER 2
18 CY-1A7880-53430 BULB 2
19 CY-22137-130000 WASHER, 13 2
20 CY-22217-130000 WASHER, SPRING 13 2
21 CY-1A7880-53100 NUT,1/2-20 UNF 2
