Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-194990-22130 NUT W/WASHER 6 2
2 CY-198072- 60590 BOLT M6X20 4
3 CY-198072- 60590 BOLT M6X20 2
4 CY-198072- 60590 BOLT M6X20 6
5 CY-198072- 60590 BOLT M6X20 2
6 CY-1A8250-60610 INSULATOR, HOOD 1
7 CY-1A8250-60620 INSULATOR,HOOD LOWER 1
8 CY-1A7180-60750 WEATHER STRIP, 1
9 CY-1A8240-60900 HINGE ASSY, HOOD 1
10 CY-1A7180-61050 NET ASSY, HOOD 1
11 CY-1A7180-61070 NET L, GRILL 1
12 CY-1A7180-61080 NET R, GRILL 1
13 CY-1A8265-61100 HOOD ASSY, TOP 1
14 C Y-1A 82 50 - 6113 0 HOOD ASSY, LOWER L 1
15 C Y-1A 82 50 - 6114 0 HOOD ASSY, LOWER R 1
16 C Y-1A 82 65 - 6118 0 BRACKET, HOOD LOWER 2
17 CY-1A8265- 61190 RUBBER, HOOD 1
18 CY-1A8265-61240 SCREW, #10-32X3/8 8
19 CY-1A8265-61250 ROD CMP, HOOD LH 1
20 CY-1A8265-61280 ROD CMP, HOOD RH 1
21 CY-1A8265-61300 STAY ASSY, LOCK 1
22 CY-1A8070 -61330 COLLAR, 10X15X10 6
23 CY-1A8250-61400 SPRING, GAS 700 1
24 CY-1A7180-61410 URETHANE, HOOD UPPER 1
25 CY-194420-61640 SCREW 5X16 14
26 CY-194420-61640 SCREW 5X16 6
27 CY-194420-61640 SCREW 5X16 6
28 CY-1A7180618101 STAY, HOOD SIDE 2
29 CY-194200-65611 NUT M5,SPEED 6
30 CY-22137-050000 WASHER 5, POLISHED 8
31 CY-22137-100000 WASHER 10,POLISHED 1
32 CY-22157-060000 WASHER 6 6
33 CY-22372-100000 SNAP PIN 10 1
34 CY-26106-080122 BOLT M 8X 12 PLATED 2
35 CY-26106-080122 BOLT M 8X 12 PLATED 4
36 CY-26106-080162 BOLT M 8X 16 PLATED 2
37 CY-26589-060102 SCREW M 6X 10 4
38 CY-26589-060102 SCREW M 6X 10 6
Copyright 2011 Cub Cadet Yanmar LLC
191
Fig 109. Hood
