Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-194990-22140 NUT W/WASHER 8 2
2 CY-194990-22140 NUT W/WASHER 8 1
3 CY-194990-22140 NUT W/WASHER 8 1
4 CY-1A8240-62561 SUB-STEP ASSY, 1
5 CY-1A8240-62660 SUPPORT ASSY, REAR R 1
6 CY-1A8240-62710 SUPPORT ASSY, SCV 1
7 CY-1A8240-62850 SUPPORT,FRONT L ASSY 1
8 CY-1A8240-62860 SUPPORT,FRONT R ASSY 1
9 CY-22217-160000 SPRING WASHER 16 4
10 CY-26106-080162 BOLT M 8X 16 PLATED 2
11 CY-26106-080162 BOLT M 8X 16 PLATED 2
12 CY-26106-100202 BOLT M10X 20 PLATED 2
13 CY-26116-160402 BOLT M16X 40 PLATED 4
Copyright 2011 Cub Cadet Yanmar LLC
199
Fig 115. Step Stay 1
