Fig 10. Tank Parts
Ref.
Part Number Description Qty
1 CY-1A8250-04250 ANGLE ASSY, TANK 2
2 CY-1A8250-04430 HOSE, FUEL 1
3 CY-1A8250-04280 TUBE, CORRUGATE 13 2
4 CY-1A8250-04870 CLAMP, HOSE 1
5 CY-1A8250-21180 COVER, HOUSING 1
6 CY-194990-22140 NUT W/WASHER 8 2
7 CY-1A7130-48110 CLAMP, PIPE 1
8 CY-1A8250-04280 TUBE, CORRUGATE 13 2
9 CY-1A8300-51210 BAND, REPEAT 1
10 CY-194680-51670 BAND 2
11 CY-194680-51670 BAND 5
12 CY-194680-51670 BAND 1
13 CY-114270-59010 CLIP, HOSE 2
14 CY-114270-59010 CLIP, HOSE 2
15 CY-114270-59010 CLIP, HOSE 2
16 CY-114270-59010 CLIP, HOSE 2
17 CY-1A8250-63890 SEAL,FENDER 2
18 CY-1A8250-63800 BRACKET ASSY, TANK 1
19 CY-1A8250 - 65870 BRACKET, SMV ASSY 1
20 CY-22157-080000 WASHER 8 2
21 CY-22157-080000 WASHER 8 2
22 CY-23980-730550 HOSE 7.3* 550 1
23 CY-23980 -731700 HOSE, 7.3X1700 2
24 CY-26106-060122 BOLT M 6X 12 PLATED 2
25 CY-26106-080162 BOLT M 8X 16 PLATED 2
26 CY-26106-080162 BOLT M 8X 16 PLATED 1
27 CY-26106-080202 BOLT M 8X 20 PLATED 2
28 CY-26106-080702 BOLT M 8X 70 PLATED 1
29 CY-26346-080002 U-NUT M 8 2
30 CY-1A7882-85630 HOLDER, SMV 1
31 CY-26106-080202 BOLT M 8X 20 PLATED 2
32 CY-1A8250 - 04290 CUSHION,TANK 1
