Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-1A8240-15500 COLUMN UNIT,STEERING 1
2 CY-1A8240-15240 BEARING, 6904LLU 1
3 CY-1A8240-15320 SHAFT, STEERING 1
4 CY-1A8240-15600 COLUMN ASSY, STG 1
5 CY-24550-015080 BEARING, 15 X 8 2
6 CY-1A8240-27030 COLLAR, 8.2X14X5.3 2
7 CY-1A8240-27050 COLLAR, 12X8X10 1
8 CY-1A8240-27090 PIN, CONNECTING 1
9 CY-198200-27240 SPRING, RETURN 1
10 CY-1A8240-27250 ARM ASSY, REVERSER 1
11 CY-24550-012080 BUSH 12X 8 1
12 CY-1A8240-27400 SHAFT, REVERSER 1
13 CY-1A8240-27460 LEVER, REVERSER 1
14 CY-22137-080000 WASHER 8, POLISHED 2
15 CY-22242-000200 CIRCLIP 20 2
16 CY-22252-000370 CIRCLIP 37 1
17 CY-26106-080352 BOLT M 8X 35 PLATED 2
18 CY-26346-080002 U-NUT, M8 2
19 CY-1A7180-15710 PIN,TILT LOCK 1
20 CY-1A7640-15710 BUSSING,TILT 4
21 CY-1A8240-15720 COLLAR, 17.3X10X22 2
22 CY-1A8240-15730 WASHER, 10.5X44X2.3 2
23 CY-1A8250-17470 BOOT, STEERING 1
24 CY-198200-18350 KNOB;REVERSER LEVER 1
25 CY-198273-18360 KNOB, ORANGE 1
26 CY-198200-18370 LABEL, 1
27 CY-198290-37510 SPRING,RETURN 1
28 CY-22217-100000 SPRING WASHER 10 1
29 CY-26106-100402 BOLT M10X 40 PLATED 2
Copyright 2011 Cub Cadet Yanmar LLC
73
Fig 26. Steering Column
