Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-198220-11520 BOLT 12X38 2
2 CY-198240-11640 BOLT M12X 46 2
3 CY-1A8275-17100 CYLINDER ASSY, PST 1
4 CY-1A8275-17260 BEARING, 35 X 15 2
5 CY-1A8275-17310 CAP, CYLINDER L 1
6 CY-1A8275-17320 CAP, CYLINDER R 1
7 CY-1A8275-17330 PACKING, 35 2
8 CY-1A8275-17340 RING, BACKUP 2
9 CY-1A8275-17350 TUBE, CYLINDER 1
10 CY-1A8275-17360 ELBOW ASSY 2
11 CY-24315-000110 O-RING 1B P-11.0 2
12 CY-1A8275-17400 ROD ASSY, PST 1
13 CY-22242-000300 CIRCLIP 30 2
14 CY-1A8275-17430 SCRAPER,35 2
15 CY-1A8275-17440 PACKING, 60 2
16 CY-1A8275-17480 RING, BACKUP 55 2
17 CY-1A8275-17490 PACKING,RGU 55 1
18 CY-22312-100200 PARALLEL PIN, M10X20 2
Copyright 2011 Cub Cadet Yanmar LLC
77
Fig 28. Pst Cylinder
