Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
87
Fig 36. Transmission Case
Ref.
Part Number Description Qty
1 CY-194197-21170 PLUG 17,BORE 1
2 CY-198535-24120 NUT 16 2
3 CY-198212-24140 GASKET, TRANS. 1
4 CY-1A7350 -24160 RETAINER, BEARING 1
5 CY-1A8275-24220 HOUSING ASSY, TRANS. 1
6 CY-198240-24120 STUD 16*45 2
7 CY-1A8275-24230 HOUSING, TRANS 1
8 CY-198240-24530 STUD 12*45 2
9 CY-22312-100180 PARALLEL PIN 10X 18 2
10 CY-26216-080802 STUD M 8X 80 PLATED 2
11 CY-26218-120502 STUD,BOLT 12 X 50 2
12 CY-27260-300000 COVER, BLIND 1
13 CY-198218-24240 COVER, REAR 1
14 CY-198212-24320 GASKET, REAR COVER 1
15 CY-198071-24340 COLLAR 13X17X14 2
16 CY-198133-24380 COUPLING 140=3 1
17 CY-198255-24460 PLATE, OIL SEAL 1
18 CY-198240244803 COVER 1
19 CY-198212-24510 COVER, REAR COVER 1
20 CY-198240246902 CAP ASSY 1
21 CY-198240249003 COVER, STRAINER 1
22 CY-1A8275-24960 GAUGE ASSY, OIL 1
23 CY-1A8275-24980 GAUGE, OIL 1
24 CY-194850-24990 TUBE 1
25 CY-194322-24980 PLUG 1/2-NPT 1
Ref.
Part Number Description Qty
26 CY-194130-26350 SEAL TC 426009, OIL 1
27 CY-119860-34810 GUIDE, DIPSTICK 1
28 CY-194850-42500 CAP, OIL 33 1
29 CY-194312467502 PLUG PF3/8 1
30 CY-194640 -73180 PIN, LOWER LINK 2
31 CY-194555-77910 GASKET 1
32 CY-22217-120000 SPRING WASHER 12 2
33 CY-22217-160000 SPRING WASHER 16 2
34 CY-22312-100180 PARALLEL PIN 10X 18 2
35 CY-23491-140002 PLUG 14 2
36 CY-24311-000160 O-RING 1A P-16.0 2
37 CY-24311-000500 O-RING 1A P-50.0 1
38 CY-24321-000650 O-RING 1A G-65.0 1
39 CY-24321-000750 O-RING 1A G-75.0 1
40 CY-24351-240300 O-RING 1A 2030 1
41 CY-26013-140352 BOLT W/WASHER 14X35 4
42 CY-26106-080162 BOLT M 8X 16 PLATED 2
43 CY-26106-080202 BOLT M 8X 20 PLATED 2
44 CY-26106-080202 BOLT M 8X 20 PLATED 2
45 CY-26106-080302 BOLT M 8X 30 PLATED 10
46 CY-26106-080402 BOLT M 8X 40 PLATED 2
47 CY-26106-100252 BOLT M10X 25 PLATED 4
48 CY-26106-120502 BOLT M12X50 2
49 CY-26106-120652 BOLT, 12 X 65 2
50 CY-26716-120002 NUT 12 2
