Fig 3. Flywheel Housing & Oil Sump
Ref.
Part Number Description Qty
1 CY-129100-01580 PIN, PARALLEL 2
2 CY-129558-01620 HOUSING, FLYWHEEL 1
3 CY-194450-11190 PLUG 15 6
4 CY-26206-100252 BOLT M10X25 8
5 CY-129550 -01702 SUMP, LUB.OIL 1
6 CY-729429-01721 COVER ASSY, OIL SUMP 1
7 CY-105425-01690 PLUG, M16 1
9 CY-22190-160002 WASHER, 16 1
10 CY-129555-01750 PIPE, KNOCK 1
11 CY-26106-080122 BOLT M 8X 12 PLATED 20
12 CY-26106-080502 BOLT M 8X 50 PLATED 8
13 CY-26106-081002 BOLT M 8X100 PLATED 14
14 CY-26106-081202 BOLT M 8X120 PLATED 4
15 CY-129100-01580 PIN, PARALLEL 2
16 CY-729402-01650 CASE ASSY, OIL SEAL 1
18 CY-129120 -01780 SEAL, OIL 1
19 CY-129486-01670 BOLT, M8X30 9
