14 Section 4— controlS & FeatureS
Fuel Shut-Off Valve
The fuel shut-off valve is located on top of the fuel tank. When
turned in a clockwise direction until it stops, it will shut off the flow
of fuel to the engine. When turned in a counterclockwise direction
Figure 1-1
NOTE: Close this valve if you are not going to run the mower for a
Transmission Bypass Rods (Not Shown)
The transmission bypass rods (one for each the RH and LH
transmission) are located beneath the frame platform, just inside
When engaged, the two rods open a bypass within the
hydrostatic transmissions, which allows the tractor to be pushed
short distances by hand. Refer to the Maintenance & Adjustments
section for instructions on using the bypass feature.
CAUTION: Never tow your tractor. Towing the
tractor with the rear wheels on the ground may
cause severe damage to the transmissions.
Transmission Oil Expansion Reservoir (Not Shown)
The transmission oil expansion reservoir is connected by hoses to
the RH and LH transmission assemblies, and is located beneath
the seat box. The function of the reservoir is to hold the natural
expansion of transmission oil that occurs as the transmission
Under normal operating conditions, no oil should be added
approximately ⁄
Figure 1-2
NOTE: Prior to the initial operation of the tractor, the oil level in
the reservoir may be slightly higher than the maximum due to air
air from the lines and the oil level will settle to the maximum.
