10 se c t i O n 2— as s e M b l y & se t -up
Installing the LPG Tank


sure that the alignment pin fits into the slot on the bottom

When the tank is in place, secure it by locking down the 2.



NOTE: The hose has left-handed threads to prevent
improper usage.
Steering Wheel Column
The steering wheel column is tilted all the way back for shipping
purposes. To tilt the column forward, press the steering tilt pedal.
Release the steering tilt pedal when the column is in the desired
position.
Steering Wheel
Remove the hardware for attaching the steering wheel 
from beneath the steering wheel cap. Carefully pry off the
steering wheel cover to remove the hardware.
With the wheels of the tractor pointing straight forward, 2.
place the steering wheel over the steering shaft.


4.

place.
Steering Wheel Cover
Hex Screw
Flat Washer
Steering Wheel
Steering Wheel
Column
Belleville Washer
Figure 3-5
Cylinder Valve Guard
Alignment Pin
Slot
Figure 3-3
A
A
B
C
Figure 3-4

Cub Cadet Z-Force S 48 Specifications

General

Engine Brand	Kohler
Engine Power	24 hp
Cutting Width	48 inches
Fuel Capacity	3.5 gallons
Transmission	Hydro-Gear ZT-2800
Transmission Type	Hydrostatic
Deck Material	Steel
Deck Construction	Fabricated
Deck Material Gauge	10-gauge
Number of Blades	3
Type	Zero-Turn
Cutting Height	1.5 - 4 inches
Warranty	3-year limited
