23se c t i O n 6 — Ma i n t e n a n c e & ad j u s t M e n t s
Measure the distance from the outside of the left blade 2.
tip to the ground and the distance from the outside of the




NOTE: The front right deck hanger link is not adjustable
and is used to help adjust the other hanger links.
Using a wrench, raise or lower the left side of the deck by 4.

The deck is properly leveled when both blade tip measurements
are equal. Retighten the hex bolt on the front left deck hanger
bracket when proper adjustment is achieved.
Leveling the Deck (Front To Rear)
NOTE: 

information regarding tire pressure. Always level the deck side to
side before front to rear.
The front of the deck should be between ⁄ and ⁄ lower than
the rear of the deck. Adjust if necessary as follows:

lift pedal in a middle position.
Rotate the blade nearest the discharge chute so that it is 2.
parallel with the tractor.
Measure the distance from the front of the blade tip to the 
ground and the rear of the blade tip to the ground. The
first measurement taken should be between ⁄ and ⁄ less
than the second measurement.
Determine the approximate distance necessary for proper 4.
adjustment and proceed, if necessary.
5.

Using a wrench, raise or lower the left and right side of the 6.

Deck Spindle


purpose lithium grease. Using a grease gun, apply two strokes
(minimum) or sufficient grease to the spindle shaft.
Tires
WARNING! Never exceed the maximum inflation
pressure shown on the sidewall of the tire.

recommended or maximum psi. Do not overinflate. Uneven tire
pressure could cause the cutting deck to mow unevenly.
Adjustments
NOTE: 

information regarding tire pressure.
WARNING! 
ignition key and engage the parking brake before

heavy gloves when handling the blades.
Leveling the Deck (Side to Side)
NOTE: 

information regarding tire pressure. Always level the deck side to
side before front to rear.
NOTE: When leveling the deck side-to-side, make sure the two
rear adjustment gears are set in the middle of the adjustment
range.
If the cutting deck appears to be mowing unevenly, a side to side
adjustment can be performed. Adjust if necessary as follows:
With the tractor parked on a firm, level surface, place the deck 
lift pedal in a middle mowing position and rotate both outside
blades so that they are perpendicular with the tractor.
Adjustment
Gear
Hex Bolt
Figure 6-6
Figure 6-5

Cub Cadet Z-Force S 48 Specifications

General

Engine Brand	Kohler
Engine Power	24 hp
Cutting Width	48 inches
Fuel Capacity	3.5 gallons
Transmission	Hydro-Gear ZT-2800
Transmission Type	Hydrostatic
Deck Material	Steel
Deck Construction	Fabricated
Deck Material Gauge	10-gauge
Number of Blades	3
Type	Zero-Turn
Cutting Height	1.5 - 4 inches
Warranty	3-year limited
