The winch is self-braking and will prevent the roof/hard floor from

further opening. (

It is important that the winch strap winds on

and off from the top of the winch spool, and NOT from under

or the bottom of the winch spool)

7. Return to the winch and continue to wind out the roof/hard floor

section until it reaches the ground,

then continue to unwind the

winch ensuring the winch strap is quite loose at this point

(there needs to be some slack in the strap to allow for the

extension of the rear tent bow). 12 unwinds will do the job!

8. The gap between the hard floor and the trailer body should be

minimal and reasonably parallel. You can now adjust the four (4)

adjustable legs on the hard floor. The roof of the trailer has now

become the hard floor of the opened Cub.

9. Lift the canvas over the trailer body at the side where

the trailer body angles downwards at approximately

45 degrees, ensuring care is taken to raise the canvas

above and over the weather seal to avoid any

unnecessary damage to the weather sealing of the

trailer.

10. Walk around the

Cub

and affix all bungee loops on the canvas tent

to the corresponding knob on the

Cub

body.

11. Release the grey snap lock adjusters on either side

of the rear tent bow and push the rear tent bow

outwards

firmly

with both hands. Secure the

adjusting screws to lock into position, then insert

the two support poles into the two rear corners of

the Camper.

Lift canvas over body

Push the rear bow outwards

Cub 2.2 Series - Page 6
