© CUB CAMPERS • 2.2 OWNER’S MANUAL V2 • 20/12/2022 PAGE 9 of 32
3. CLOSING THE CAMPER TRAILER
1. Ensure that all lights/appliances are unplugged from the power
source before the camper is closed.
2. Ensure the internal bed has been lowered (in the down position)
and that all windows are closed. If there are pillows on the bed,
move them to the foot of the bed.
3. Close the rear door zip, leaving the front zip open to allow exit.
4. Remove the two (2) rear tent bow support poles and stow on to the
bed for use when next setting up the
Cub
.
5. Release the locking screw on the slide bracket and lower the
doorway bar down to the stopper at the bottom of the centre
upright bar, then tighten the locking screw.
IT IS IMPORTANT THAT THE SLIDE BRACKET LOCKING SCREW IS
TIGHTENED AFTER LOWERING THE DOORWAY BAR. YOU CAN
DO THIS AFTER EXITING THE CAMPER IF IT IS EASIER.
6. Release the two adjusters on the rear tent bow. Allow the rear bow
to collapse in (within approximately 15 cms of the adjusters), then
re-tighten the adjusters making sure it is even on both sides.
To Next Page
