Attention: Ensure when adjusting the height of the saddle that
the seat pin is not pulled out further than the maximum height!
Failure to comply with this could result in serious material
defects or accidents! (Fig. 30)
VII. Fitting the pedals
Remove the pedals from the accessoriespackage, if you have
ordered pedals.
Identify the right-hand pedal and screw it in a clockwise
direction onto the right-hand crank (Fig. 29)
Screw the left-hand pedal in an anti-clockwise direction onto
the left-hand crank
Tighten both pedals with a 15 mm spanner and, after a few
miles, check once again that they are still tightly tted (Fig. 30)
Fig. 29 Fitting the right-hand pedal
to the right-hand crank
Fig. 30 Tighten the right-hand
pedal in a clockwise direction
Important: The right-hand crank is always on the side of the
chainset.
Attention: Failure to note the markings on the pedals or trying
to t the pedals with force will inevitably damage the threads!
