Cudy POE10 User Manual

6
Maximum Distances for Power Sources
Multiple PoE Extenders can be connected every 100 meters to obtain greater distances.
The actual figures depend on operating conditions. The range is over 24AWG or heavier
Cat-5s or Cat-6 cable except where specified.
Examples for medium power PoE devices (that are PoE Class 2 or require less than 6W).
PoE Source
Maximum Distances
PoE switch
(802.3af, output voltage 50V)
300 meters
15W mid-span
(802.3af, output voltage 50V)
300 meters
PoE+ switch
(802.3at, output voltage 50V)
400 meters
30W mid-span
(802.3at, output voltage 50V)
400 meters
Examples for full power PoE devices (that are PoE Class 0 or 3, or require less than 12W).
PoE Source
Maximum Distances
PoE switch
(802.3af, output voltage 50V)
200 meters
15W mid-span
(802.3af, output voltage 50V)
200 meters
PoE+ switch
(802.3at, output voltage 50V)
300 meters
30W mid-span
(802.3at, output voltage 50V)
300 meters
Examples for PoE+ devices (that are PoE Class 4 that require less than 22W or are
802.3at-compliant).
PoE Source
Maximum Distances
PoE switch
(802.3af, output voltage 50V)
Not applicable
15W mid-span
(802.3af, output voltage 50V)
Not applicable
PoE+ switch
(802.3at, output voltage 50V)
200 meters
30W mid-span
(802.3at, output voltage 50V)
200 meters

Cudy POE10 Specifications

General

Type	-
Duplex system	Full, Half
Plug and Play	Yes
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	100 m
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3af, IEEE 802.3at
Cable types supported	Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Cat7e, Cat8, Cat8.1
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Product color	White
LED indicators	Activity, Link, PoE
Quantity per pack	1 pc(s)
Power over Ethernet (PoE) voltage	- V
Total Power over Ethernet (PoE) budget	22 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-40 - 45 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Pin assignment & polarity	1/2 (-), 3/6 (+), 7/8 (-), 4/5 (+)

Weight and Dimensions

Depth	60 mm
Width	145 mm
Height	40 mm
