Cudy POE100 User Manual

5
LED and Interface Explanation
PORT
Green
PoE injector got 100-240V power input.
Red
The terminal equipment connected to DATA&POWER
OUT port is powered.
AC Socket
Connect with AC cable.
DATA IN
Connect to the Ethernet device with cable to transmit data.
DATA OUT
Connect to the PD device with UTP cable to supply power.
Specifications
Model
POE100/POE500
Power
100-240V AC
Ethernet
POE100: 10/100/1000M
POE500: 10/100/1000M/2.5Gbps
Network
protocol
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
IEEE802.3ab (1000Base-TX)
IEEE802.3bz (2.5GBase-T)
IEEE802.3x (flow control)
PoE protocol
IEEE802.3af (15.4W)
IEEE802.3at (25.4W)
Industry
standard
EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD), EN61000-4-4 (EFT)
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Network
medium
10Base-T: Cat3, Cat4, Cat5 or above UTP (≤100m)
100Base-TX: Cat5 or above UTP (≤100m)
1000Base-TX: Cat5 or above UTP (≤100m)
Working
temperature
0 ~ 40 °C
Storage
temperature
-40 ~ 80 °C

Cudy POE100 Specifications

General

Brand	Cudy
Model	POE100
Category	Switch
Language	English
