Cat. No. 01020478

Rev. A

2

11/26/07

DCO # 010173

Installation

and Operation

Instructions

with Parts List

Culligan

®

Iron-Cleer

®

Water Filters

Models from 2007

© 2007 Culligan International Company

Table of Contents

Other manuals for Culligan Iron-Cleer

Owner's Guide23 pages

Questions and Answers:

K
Kevin James Jr.Aug 18, 2025
Why is there iron bleed-through or staining in my Culligan Water Filtration System?
- V
  vphillipsAug 19, 2025
  If you notice iron bleed-through or staining with your Culligan Water Filtration System, it could be due to several reasons. The drain line flow control might be plugged and needs cleaning or replacement. There might be insufficient water supply from the well, so check for the minimum flow and pressure requirements of the system. The aeration tank inlet diffuser or pick-up tube could be plugged, requiring cleaning of the aeration assembly and shock treatment of the water supply with chlorine. Finally, the media bed might be fouled, necessitating rebedding of the filter and correction of the cause of fouling.
J
John WoodsAug 21, 2025
Why is my Culligan Water Filtration System causing blue green staining?
- J
  jeffreyvelezAug 21, 2025
  If you notice blue-green staining with your Culligan Water Filtration System, it could be due to a corrosive water condition in the copper distribution piping system, and a Cullneu® filter may be required to elevate the pH. Consult the factory. In rare cases, highly aerated water combined with a specific water supply can create a slightly corrosive condition. Install a polyphosphate cartridge filter after the Iron-Cleer Filter System to protect the distribution piping.
J
Jason MarshallAug 23, 2025
What to do if the motor is stuck on my Culligan Water Filtration System?
- D
  Dr. Luis CummingsAug 23, 2025
  If the motor is stuck in your Culligan Water Filtration System, it is recommended to call a Culligan service technician for assistance.
J
Jimmy RichardsonAug 26, 2025
What to do if my Culligan Water Filtration System is in the wrong position?
- B
  Blake MillerAug 26, 2025
  If your Culligan Water Filtration System is in the wrong position, it is recommended to call a Culligan service technician for assistance.
B
Brian NewmanAug 28, 2025
What to do if my Culligan Water Filtration System fails to regenerate?
- A
  Austin WangAug 28, 2025
  If your Culligan Water Filtration System fails to regenerate, first ensure a continuous electrical supply by checking the plug, breaker, and fuses. If the power supply is not the issue, the circuit board might be faulty and need replacement. Alternatively, the drive motor could be faulty, also requiring replacement. Lastly, the circuit board settings may be incorrect, so try resetting the circuit board.
R
Ryan HolmesAug 30, 2025
What to do if water is running to drain continuously in my Culligan Water Filtration System?
- J
  John SmithAug 30, 2025
  If water is running to drain continuously in your Culligan Water Filtration System, make sure continuous electrical service is available by checking the plug, breaker, and fuse. The circuit board may be faulty and require replacement, or the drive motor may be faulty and also require replacement. Another potential cause is foreign material lodged in the piston; in this case, disassemble and clean the control valve, and replace the seals, spacers, and piston assemblies.
L
Linda WarrenSep 1, 2025
Why is water leaking from the relief valve of my Culligan Water Filtration System?
- C
  Chelsea BrownSep 1, 2025
  If you experience water leaking from the relief valve of your Culligan Water Filtration System, it could be due to dirt lodged under the seat of the valve. Check the pressure on the system and adjust if necessary. Try cleaning or replacing the relief valve. If the issue persists, the relief valve itself may be faulty or defective, requiring replacement.
J
jonathan40Sep 4, 2025
Why is my Culligan Water Filtration System spurting air at outside water fixtures?
- T
  Tyrone SmithSep 4, 2025
  If you notice air spurting at outside or non-filtered water fixtures with your Culligan Water Filtration System, it could be due to the inlet check valve not sealing. Refer to the installation and operation manual for the correct placement of the inlet check valve. Another possibility is foreign material preventing the check valve from sealing, which would require cleaning or replacement of the check valve. Lastly, the check valve might be worn or faulty, necessitating replacement.
M
Meagan SalazarSep 6, 2025
Why is my Culligan Water Filtration System losing media through the drain line?
- S
  Sarah Ramos DVMSep 6, 2025
  If you observe a loss of media through the drain line of your Culligan Water Filtration System, it could be because a new filter was backwashed during the first 24 hours after installation. In this case, clean the drain line flow control, control valve body, seals, spacers, and piston assemblies. Alternatively, air might be passing through the filter during backwash because the bleed-off valve flow control is plugged with foreign material; clean or replace it.
A
Andrew KennedySep 8, 2025
How to reduce excessive noise during regeneration of my Culligan Water Filtration System?
- M
  Michael ThomasSep 8, 2025
  If your Culligan Water Filtration System is making excessive noise during regeneration, it may be due to an inadequate drain line size, so increase the drain line size. Alternatively, the drain line may be vibrating against other pipes, conduits, pipe hangers, heat ducts, floor joists, etc.; insulate the drain line, specifically at points of contact with other materials.

Culligan Iron-Cleer Specifications

General

Brand	Culligan
Model	Iron-Cleer
Category	Water Filtration Systems
Language	English

Summary

Introduction

Safe Practices

Guidelines and warnings for safe operation and handling of the water filter system.

Specifications

Installation

Placement

Instructions on selecting an appropriate location for the water filter and aeration tank.

Filter Tank Filling

Mount The Control Valve

Plumbing Connections

Instructions for making the necessary water line connections to the system.

Electrical Connections

Guidance on connecting the unit to a power source and transformer.

Drain Lines

Aeration Tank Installation

Circuit Board

Circuit Board Connections

Details on how to connect wires to the control circuit board.

Programming

Dip Switch Definitions

Explanation of the function of each DIP switch for system configuration.

Hidden Programming Menu

Manual Cycling

Manual Control Cycling

Start-Up

Preventative Maintenance

Recommended Preventative Maintenance

Troubleshooting Guide

Iron Bleed-through or Staining

Diagnosing and resolving issues related to iron contamination in treated water.

Water Leaking from Relief Valve

Water Running to Drain Continuously

Compressor Doesn't Run

Troubleshooting steps for a compressor that fails to operate.

Circuit Board Troubleshooting

Diagnosing and resolving issues related to the system's circuit board.

Wiring Diagram

Parts List

Control Valve Parts List

Conditioner Tank Parts List

Compressor Parts List

Aeration Parts List

Related product manuals
