14 PNEG-2223 Flex-Flo Control Unit with Auto Calibration
4. Wiring Diagrams
Flex-Flo Control Unit Used with 5 Wire Sensor
FLEX-FLO CONTROL UNIT (FLX-5350)
PROXIMITY SWITCH (AP-1002)
L1
L2
L3
M1
M2
M3
Incoming Power Flex-Flo Motor
Auxiliary Switch
BLACK 3
BLACK 1
BLUE
BROWN
GREEN
WHITE
BLACK
GREEN
WHITE
BLACK
L1
L2
IN
OUT
COM.
N.O.
Relay
Output
Signal
Signal
Power
Power
N.O. - BLACK 4 (NOT USED)
N.C. - BLACK 3
COM. - BLACK 1
LINE - BLUE
LINE - BROWN
TAPE FOR PROTECTION
FLEX-FLO
MOTOR
GND
L2
L1
208-230VAC
POWER SUPPLY
