11
Each of the cooking zones has a separate controller with 6 heat settings:
Choose the control for the burner you want to use.
Heat Setting Suitability
1 Keeping food warm
2 - 3 Cooking at low heat
4 - 6 Cooking and boiling
1. Turn the required zone control clockwise to increase
the temperature to the desired level.
2. When turning the hob o, turn the control in a clockwise direction to the o mark ‘O’.
Residual heat functions
After using the hob there will be heat stored in the vitroceramic glass. This is called residual heat. If the residual
heat level is greater than 60°C a warning lamp will show for the cooking zone above this temperature. There are
separate warning lights for each cooking zone.
Before Use
Before using your new hob, please:
• Read this manual fully taking special note of the ‘Safety Warnings’ section.
• Plug the hob into the electricity supply and turn it on so that the ignition circuit will work.
Remove any protective lm that may still be on your ceramic hob.
Using the Hob
* All images are for indication only; please refer to your individual unit for actual item.
O
Low level
heat
5
6
4
3
2
1
0
Cooking/
boiling
Warm
This appliance is for cooking purposes only. It must not be used for other purposes, e.g. room heating.
If the power supply to the hob is disconnected while a residual temperature warning light is on,
the warning light will ash when the power is reconnected. The display will stop ashing once the
maximum residual heat time has expired, or one of the cooking zones is activated.
CCHOBKN13_IB.indd 11 12/04/2013 12:12
